Solis 60 4WD

Solis 60 4WD

The Solis 60 Tractors are designed to be a Tough, Rugged, Value for people needing a durable, affordable machine for their farm or ranch.

Solis 60 4WD

The SOLIS 60 4 Wheel Drive (4WD) was specially designed for when the big leagues just aren't big enough. With a powerful ITL engine, a rugged12x12 gear transmission, and a longer wheelbase, the SOLIS 60 contains enough power to go up against any project and come out on top. The expertly designed front end loader was created with the power and weight of the SOLIS 60 in mind. And with the weight of the SOLIS 60 that was no easy feat.

  • 12x12 Gear Transmission
  • ITL Engine
  • Lengthened Wheelbase

TOUGH. RUGGED. VALUE.

No matter the additions, growth, or evolution - your SOLIS will always be your SOLIS. The commitment to providing rough and tumble machines for feather bed prices will never stop being a SOLIS priority. Simple to operate, easy to maintain, and straight-forward to understand, your SOLIS 60 is still the tractor next door - just all grown up.

Solis 60 4WD

Specifications

Engine

Engine Model 3100 FLT, Inline FIP with Coldstart
HP Category 60 HP
Number of Cylinders 3
Aspiration Turbocharged
Cubic Capacity (ci) 169.65
Rated RPM (+/- 25mm) 2100

Transmission

Drive 4WD
Clutch Dual
Gearbox 8F+2R
Transmission Type Mechanical, Synchromesh

Brakes

Type Oil Immersed Brakes
Type of Actuation Independent, Hand Operated

Differential Lock

Standard

PTO

PTO HP 48.67
PTO (rpm) 540@2100
PTO (actuation) Independent, Hand Operated

Steering

Power Steering

Hydraulics

3-point linkage CAT-II
3-point lift capacity @ ball ends (Lbs) 4,814
Auxilliary hydraulic circuit 2SA/ 2DA
Implement hydraulic flow (GPM) 8.45
Steering hyrdaulic flow (GPM) 4.18

Capacities

Fuel tank 19.81

Tires

AG - Front 9.5-24
AG - Rear 16.9-28

Dimensions & Weights

Weight (lbs) 6,503
Wheel Base 87.28 in
Total Length (in) 157.9
Total Width (in) 80.5
Height (in) Up to ROPS 98.43

Warranty and service

A 5 year limited warranty on the powertrain is standard on all new Yanmar Utility tractor purchases. Yanmar attachments are covered by a one-year limited warranty.
